1.5 Component Names
34 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
■ Three-Phase AC200 V CIMR-E2A0169A to 0312A
Three-Phase AC400 V CIMR-E4A0139A to 0208A
Figure 1.3
Figure 1.4 Exploded view of IP00 Enclosure Type Components (CIMR-E4A0165A)
A – Mounting hole H – Front cover
B – Heatsink I – USB port (type-B)
C – Optional 24 V DC power
supply connector cover
J – Digital operator
D – Terminal board K – Front cover screw
E – Fan guard L – Drive cover
F – Cooling fan M – Terminal cover
G – Fan unit case
A
B
D
C
E
F
G
H
I
K
J
L
M
YEC_TMonly
SIEP_C710616_35.book 34 ページ ２０１５年１１月３０日 月曜日 午後２時２分
