E.1 Drive and Motor Specifications
462 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
E.1 Drive and Motor Specifications
◆ Drive
A separate record should be kept that lists drive specifications and motor specifications.
◆ Motor
■ Induction Motor
Note: These values must be entered as part of the Auto-Tuning process.
■ Permanent Magnet Motor
Note: These values must be entered as part of the Auto-Tuning process.
Items Description
Model CIMR-E
Serial Number
Date of Usage
Items Description Items Description
Manufacturer Motor Rated Current (T1-04) A
Model Motor Base Frequency (T1-05) Hz
Motor Rated Power (T1-02) kW Number of Motor Poles (T1-06)
Motor Rated Voltage (T1-03) V Motor Base Speed (T1-07) r/min
Items Description Items Description
Manufacturer PM Motor Rated Current (T2-06) A
Model PM Motor Base Frequency (T2-07) Hz
PM Motor Rated Power (T2-04) kW Number of PM Motor Poles (T2-08)
PM Motor Rated Voltage (T2-05) V
PRG : 8000
IP20
IND.CONT.EQ.
7J48 B
CIMR-ET4A0004FAA
YASKAWA ELECTRIC CORPORATION
2-1 Kurosaki-shiroishi, Yahatanishi-Ku, Kitakyushu 806-0004 Japan
MADE IN JAPAN
:
: AC3PH 380-480V 50/60Hz 4.3A
: AC3PH 0-480V 0-200Hz 4.1A
: 3.2 kg
:
:
: E131457
PASS
MODEL
MAX APPLI. MOTOR : 1.5kW REV : A
INPUT
OUTPUT
MASS
O / N
S / N
FILE NO
KCC - REM - Yec
- CIMR - E1000
- XXX
TYPE 1 ENCLOSURE
AC drive model
Input specifications
Output specifications
Lot number
Serial number
Software version
Amps
YEC_
com
-
mon
