B.3 Parameter Table
390 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
q: DriveWorksEZ Parameters
r: DriveWorksEZ Connection Parameters
T: Motor Tuning
Enter data into the following parameters to tune the motor and drive for optimal performance
T1: Induction Motor Auto-Tuning
o4-12
(512H)
kWh Monitor Initialization
0: No action U4-10 and U4-11 monitor data is not reset when the drive is initialized (A1-03).
1: Reset kWh data U4-10 and U4-11 monitor data is reset when the drive is initialized (A1-03).
Default: 0
Min: 0
Max: 1
251
o4-13
(528H)
Number of Run Commands
Counter Initialization
0: No action Number of Run commands counter is not reset when the drive is initialized (A1-
03).
1: Reset the run command Counter. Number of Run commands counter is reset when the drive
is initialized (A1-03).
Default: 0
Min: 0
Max: 1
252
No. (Addr.) Name Description Setting Page
q1-01 to q6-07
(1600H to
1746H)
DriveWorksEZ Parameters
Reserved for DriveWorksEZ
Refer to Help in the
DWEZ software.
252
No. (Addr.) Name Description Setting Page
r1-01 to
r1-40
(1840H to
1867H)
DriveWorksEZ Connection
Parameters 1 to 20 (upper/lower)
DriveWorksEZ Connection Parameters 1 to 20 (upper/lower)
Default: 0
Min: 0
Max: FFFFH
252
No. (Addr.) Name Description Setting Page
T1-01
(701H)
<37>
<6> Default setting value varies by the drive model (o2-04).
<10> Default setting is determined by the control mode (A1-02).
<18> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
<37> The availability of certain Auto-Tuning methods depends on the control mode selected for the drive.
<38> Default setting value differs depending on the motor code value and motor parameter settings.
Auto-Tuning Mode Selection 2: Stationary Auto-Tuning for Line-to-Line Resistance
3: Rotational Auto-Tuning for V/f Control (necessary for Energy Savings and Speed Estimation
Speed Search)
Default: 2
Min: 2
Max: 3
<10>
116
T1-02
(702H)
Motor Rated Power
Sets the motor rated power as specified on the motor nameplate.
Note: Use the following formula to convert horsepower into kilowatts: kW = HP x 0.746.
Default:
<6>
Min: 0.00 kW
Max: 650.00 kW
116
T1-03
(703H)
<18>
Motor Rated Voltage
Sets the motor rated voltage as specified on the motor nameplate.
Default: 200.0 V
Min: 0.0 V
Max: 255.0 V
117
T1-04
(704H)
Motor Rated Current
Sets the motor rated current as specified on the motor nameplate.
Default:
<6>
Min: 10% of drive rated
current
Max: 200% of drive
rated current
117
T1-05
(705H)
Motor Base Frequency
Sets the rated frequency of the motor as specified on the motor nameplate.
Default: 50.0 Hz
Min: 0.0 Hz
Max: 200.0 Hz
117
T1-06
(706H)
Number of Motor Poles
Sets the number of motor poles as specified on the motor nameplate.
Default: 4
Min: 2
Max: 48
117
T1-07
(707H)
Motor Base Speed
Sets the rated speed of the motor as specified on the motor nameplate.
Default: 1450 r/min
Min: 0 r/min
Max: 24000 r/min
117
T1-11
(70BH)
Motor Iron Loss
Sets the iron loss for determining the Energy Saving coefficient.
The value is set to E2-10 (motor iron loss) set when the power is cycled. If T1-02 is changed, a
default value appropriate for the motor capacity that was entered will appear.
Default:
<38>
Min: 0 W
Max: 65535 W
117
No. (Addr.) Name Description Setting Page
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
OLV/PMV/f
common_
TMonly
OLV/PMV/f
common_
TMonly
OLV/PMV/f
common_
TMonly
OLV/PMV/f
common_
TMonly
OLV/PMV/f
common_
TMonly
OLV/PMV/f
common_
TMonly
OLV/PMV/f
common_
TMonly
OLV/PMV/f
common_
TMonly
