A.1 Three-Phase 200 V Class Drives
350 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
A.1 Three-Phase 200 V Class Drives
Table A.1 Power Ratings (Three-Phase 200 V Class)
Item
<1> The motor capacity (kW) refers to a Yaskawa 4-pole motor. The rated output current of the drive output amps should be equal to or greater than
the motor rated current.
<2> Assumes operation at the rated output current. Input current rating varies depending on the power supply transformer, input reactor, wiring
connections, and power supply impedance.
<3> DC is not available for UL/CE standards.
<4> Rated motor capacity is calculated with a rated output voltage of 220 V.
<5> Current derating is required in order to raise the carrier frequency.
<6> User adjustable
Specification
CIMR-E2A 0004 0006 0008 0010 0012 0018 0021 0030 0040 0056 0069 0081 0110 0138 0169 0211 0250 0312 0360 0415
Maximum Applicable Motor Capacity (kW) <1>
0.7 1.1 1.5 2.2 3 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110 110
Input
Input Current (A) <2> 3.9 7.3 8.8 10.8 13.9 18.5 24 37 52 68 80 96 111 136 164 200 271 324 394 471
Rated Voltage
Rated Frequency
Three-phase 200 to 240 Vac 50/60 Hz/270 to 340 Vdc
<3>
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Input Power (kVA)
2.2 3.1 4.1 5.8 7.8 9.5 14 18 27 36 44 52 51 62 75 91 124 148 180 215
Output
Rated Output Capacity (kVA) <4> 1.3 2.3 3 3.7 4.6 6.7 8 11.4 15.2 21 26 31 42 53 64 80 95 119 137 158
Rated Output Current (A) <5> 3.5 6 8 9.6 12 17.5 21 30 40 56 69 81 110 138 169 211 250 312 360 415
Overload Tolerance
120% of rated output current for 60 s
Note: Derating may be required for applications that start and stop frequently.
Carrier Frequency
1 to 15 kHz <6> 1 to 10 kHz <6>
Maximum Output Voltage (V)
Three-phase 200 to 240 V (proportional to input voltage)
Maximum Output Frequency (Hz)
200 Hz <6>
SIEP_C710616_35.book 350 ページ ２０１５年１１月３０日 月曜日 午後２時２分
To Next Page
