3.12 Connect to a PC
90 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
3.12 Connect to a PC
This drive is equipped with a USB port (type-B).
The drive can connect to the USB port of a PC using a USB 2.0, AB type cable (sold separately). DriveWizard Plus can
then be used to monitor drive performance and manage parameter settings. Contact Yaskawa for more information on
DriveWizard Plus.
Figure 3.40
Figure 3.34 Connecting to a PC (USB)
PC
(Type-B) (Type-A)
USB Cable
(Type-AB)
YEC_common
SIEP_C710616_35.book 90 ページ ２０１５年１１月３０日 月曜日 午後２時２分
