B.7 Parameters that Change with the Motor Code Selection
404 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
B.7 Parameters that Change with the Motor Code Selection
The following tables show parameters and default settings that change with the motor code selection E5-01 when Open
Loop Vector for PM motors is used.
◆ YASKAWA SMRA Series SPM Motor
Table B.8 200 V, 1800 r/min Type YASKAWA SMRA Series SPM Motor
Table B.9 200 V, 3600 r/min Type YASKAWA SMRA Series SPM Motor
No. Name Unit Default Settings
E5-01
Motor Code Selection − 0002 0003 0005 0006 0008
Voltage Class V 200 200 200 200 200
Rated Power kW 0.4 0.75 1.5 2.2 3.7
Rated Speed r/min 1800 1800 1800 1800 1800
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7
E5-03 Motor Rated Current A 2.1 4.0 6.9 10.8 17.4
E5-04 Number of Motor Poles – 8 8 8 8 8
E5-05 Motor Stator Resistance (r1) Ω 2.47 1.02 0.679 0.291 0.169
E5-06 Motor d-Axis Inductance (Ld) mH 12.7 4.8 3.9 3.6 2.5
E5-07 Motor q-Axis Inductance (Lq) mH 12.7 4.8 3.9 3.6 2.5
E5-09 Motor Induction Voltage Constant 1 (Ke) mVs/rad 0 0 0 0 0
E5-24 Motor Induction Voltage Constant 2 (Ke) mV/(r/min) 62.0 64.1 73.4 69.6 72.2
E1-04 Maximum Output Frequency Hz 120 120 120 120 120
E1-05 Maximum Voltage V 200.0 200.0 200.0 200.0 200.0
E1-06 Base Frequency Hz 120 120 120 120 120
E1-09 Minimum Output Frequency Hz 6 6 6 6 6
L3-24
Motor Acceleration Time for Inertia
Calculations
s 0.064 0.066 0.049 0.051 0.044
n8-49
d-Axis Current for High Efficiency
Control (OLV/PM)
%00000
No. Name Unit Default Settings
E5-01
Motor Code Selection − 0103 0105 0106 0108
Voltage Class V 200 200 200 200
Rated Power kW 0.75 1.5 2.2 3.7
Rated Speed r/min 3600 3600 3600 3600
E5-02 Motor Rated Power kW 0.75 1.5 2.2 3.7
E5-03 Motor Rated Current A 4.1 8.0 10.5 16.5
E5-04 Number of Motor Poles – 8 8 8 8
E5-05 Motor Stator Resistance (r1) Ω 0.538 0.20 0.15 0.097
E5-06 Motor d-Axis Inductance (Ld) mH 3.2 1.3 1.1 1.1
E5-07 Motor q-Axis Inductance (Lq) mH 3.2 1.3 1.1 1.1
E5-09 Motor Induction Voltage Constant 1 (Ke) mVs/rad 0 0 0 0
E5-24 Motor Induction Voltage Constant 2 (Ke) mV/(r/min) 32.4 32.7 36.7 39.7
E1-04 Maximum Output Frequency Hz 240 240 240 240
E1-05 Maximum Voltage V 200.0 200.0 200.0 200.0
E1-06 Base Frequency Hz 240 240 240 240
E1-09 Minimum Output Frequency Hz 12 12 12 12
L3-24
Motor Acceleration Time for Inertia
Calculations
s 0.137 0.132 0.132 0.122
n8-49
d-Axis Current for High Efficiency
Control (OLV/PM)
%0000
