1.4 Drive Models and Enclosure Types
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 31
Receiving
1
1.4 Drive Models and Enclosure Types
Two types of enclosures are offered for E1000 drives.
• IP00 enclosure models are designed for installation in an enclosure panel that serves to protect personnel from injury
caused by accidentally touching live parts.
• IP20/NEMA 1, UL Type 1 enclosure models mount to an indoor wall or in an enclosure panel.
Table 1.5 describes drive enclosures and models.
Table 1.5 Drive Models and Enclosure Types
Voltage Class
<1> Removing the top protective cover from a IP20/NEMA 1, UL Type 1 enclosure drive voids NEMA 1, UL Type 1 protection but still keeps IP20
conformity.
<2> Special order required. Contact your Yaskawa sales representative.
Enclosure Type
IP20/NEMA 1, UL Type 1 Enclosure
CIMR-E
IP00 Enclosure
CIMR-E
Three-Phase
200 V Class
2A0004F <1>
2A0006F <1>
2A0008F <1>
2A0010F <1>
2A0012F <1>
2A0018F <1>
2A0021F <1>
2A0030F <1>
2A0040F <1>
2A0056F <1>
2A0069F <1>
2A0081F <1>
2A0110F <2> 2A0110A
2A0138F <2> 2A0138A
2A0169F
<2> 2A0169A
2A0211F <2> 2A0211A
2A0250F <2> 2A0250A
2A0312F
<2> 2A0312A
2A0360F <2> 2A0360A
– 2A0415A
Three-Phase
400 V Class
4A0002F
<1>
4A0004F <1>
4A0005F <1>
4A0007F <1>
4A0009F <1>
4A0011F <1>
4A0018F <1>
4A0023F <1>
4A0031F <1>
4A0038F <1>
4A0044F <1>
4A0058F <2> 4A0058A
4A0072F
<2> 4A0072A
4A0088F <2> 4A0088A
4A0103F <2> 4A0103A
4A0139F
<2> 4A0139A
4A0165F <2> 4A0165A
4A0208F <2> 4A0208A
4A0250F
<2> 4A0250A
4A0296F <2> 4A0296A
4A0362F <2> 4A0362A
– 4A0414A
– 4A0515A
– 4A0675A
– 4A0930A
– 4A1200A
