5.10 o: Operator Related Settings
248 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
◆ o2: Digital Operator Keypad Functions
These parameters determine the functions assigned to the operator keys.
■
o2-01: LO/RE (LOCAL/REMOTE) Key Function Selection
Parameter o2-01 determines whether the LO/RE key on the digital operator will be enabled or not for switching between
LOCAL and REMOTE.
Setting 0: Disabled
The LO/RE key is disabled.
Setting 1: Enabled
The LO/RE switches between LOCAL and REMOTE operation. Switching is possible during stop only. When LOCAL
is selected, the LED indicator on the LO/RE key will light up.
WARNING! Sudden Movement Hazard. The drive may start unexpectedly if the Run command is already applied when switching from
LOCAL mode to REMOTE mode when b1-07 = 1, resulting in death or serious injury. Check all mechanical or electrical connections
thoroughly before making any setting changes to o2-01 and b1-07. Table 5.32 lists the setting combinations for o2-01 and b1-07.
Table 5.32 LO/RE Key and b1-07
■ o2-02: STOP Key Function Selection
Determines if the STOP key on the digital operator can still be used to stop drive operation when the drive is being
controlled from a remote source (i.e., not from digital operator).
Setting 0: Disabled
Setting 1: Enabled
The STOP key can be used to terminate drive operation, even if the Run command source is not assigned to the digital
operator. If the drive is stopped by pressing the STOP key, the Run command must be cycled to restart the drive.
■ o2-03: User Parameter Default Value
Once drive parameters are set up completely, the values set can be saved as user-set default values using parameter o2-
03. Once this has been done, the “Initialize Parameters” parameter (A1-03) will offer the choice of “1110: User
Initialize”. Choosing A1-03 = “1110: User Initialize” will reset all parameters to the values saved as user-set defaults.
Refer to A1-03: Initialize Parameters on page 127 for details on drive initialization.
Setting 0: No change (awaiting command)
Setting 1: Set User Initialize values
The current parameter settings are saved as user-set default for a later User Initialize. Once o2-03 is set to 1 and the
ENTER key is pressed, the values are saved and the display returns to 0.
Setting 2: Clear User Initialize Values
All user-set defaults for “User Initialize” are cleared. Once o2-03 is set to 2 and the ENTER key is pressed, the values are
erased and the display returns to 0.
No. Name Setting Range Default
o2-01 LO/RE Key Function Selection 0 or 1 1
o2-01 b1-07 Switch from LOCAL to REMOTE Switch from REMOTE to LOCAL
0
0 Not possible Not possible
1 Not possible Not possible
1
0 Will not run until a new Run command is entered. Run not possible
1
If a Run command is entered, the drive will start running as
soon as the LO/RE key is pushed to change from LOCAL to
REMOTE.
Run not possible
No. Name Setting Range Default
o2-02 STOP Key Function Selection 0 or 1 1
No. Name Setting Range Default
o2-03 User Parameter Default Value 0 to 2 0
