E.3 User Setting Table
464 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
E.3 User Setting Table
Use the Verify Menu to see which parameters have been changed from their original default settings.
• The diamond below the parameter number indicates that the parameter setting can be changed during run.
• Parameter names in boldface type are included in the Setup Group of parameters.
No. Name
User
Setting
A1-00 Language Selection
A1-01 Access Level Selection
A1-02 Control Method Selection
A1-03 Initialize Parameters
A1-04 Password
A1-05 Password Setting
A1-06 Application Preset
A1-07 DriveWorksEZ Function Selection
A2-01 to
A2-32
User Parameters, 1 to 32
A2-33 User Parameter Automatic Selection
b1-01 Frequency Reference Selection 1
b1-02 Run Command Selection 1
b1-03 Stopping Method Selection
b1-04 Reverse Operation Selection
b1-06 Digital Input Reading
b1-07 LOCAL/REMOTE Run Selection
b1-08 Run Command Selection while in Programming Mode
b1-11 Drive Delay Time Setting
b1-14 Phase Order Selection
b1-15 Frequency Reference Selection 2
b1-16 Run Command Selection 2
b1-17 Run Command at Power Up
b2-01 DC Injection Braking Start Frequency
b2-02 DC Injection Braking Current
b2-03 DC Injection Braking Time at Start
b2-04 DC Injection Braking Time at Stop
b2-09 Motor Pre-Heat Current 2
b2-12 Short Circuit Brake Time at Start
b2-13 Short Circuit Brake Time at Stop
b2-18 Short Circuit Braking Current
b3-01 Speed Search Selection at Start
b3-02 Speed Search Deactivation Current
b3-03 Speed Search Deceleration Time
b3-04 V/f Gain during Speed Search
b3-05 Speed Search Delay Time
b3-06 Output Current 1 during Speed Search
b3-10 Speed Search Detection Compensation Gain
b3-14 Bi-Directional Speed Search Selection
b3-17 Speed Search Restart Current Level
b3-18 Speed Search Restart Detection Time
b3-19 Number of Speed Search Restarts
b3-24 Speed Search Method Selection
b3-25 Speed Search Wait Time
b3-27 Start Speed Search Select
b4-01 Timer Function On-Delay Time
b4-02 Timer Function Off-Delay Time
b5-01 PI Function Setting
b5-02 Proportional Gain Setting (P)
b5-03 Integral Time Setting (I)
b5-04 Integral Limit Setting
b5-06 PI Output Limit
b5-07 PI Offset Adjustment
b5-08 PI Primary Delay Time Constant
b5-09 PI Output Level Selection
b5-10 PI Output Gain Setting
b5-11 PI Output Reverse Selection
No. Name
User
Setting
b5-12 PI Feedback Loss Detection Selection
b5-13 PI Feedback Loss Detection Level
b5-14 PI Feedback Loss Detection Time
b5-15 PI Sleep Function Start Level
b5-16 PI Sleep Delay Time
b5-17 PI Accel/Decel Time
b5-18 PI Setpoint Selection
b5-19 PI Setpoint Value
b5-20 PI Setpoint Scaling
b5-21 PI Sleep Input Source
b5-22 PI Snooze Level
b5-23 PI Snooze Delay Time
b5-24 PI Snooze Deactivation Level
b5-25 PI Setpoint Boost Setting
b5-26 PI Maximum Boost Time
b5-27 PI Snooze Feedback Level
b5-28 PI Feedback Function Selection
b5-29 PI Square Root Gain
b5-30 PI Feedback Offset
b5-34 PI Output Lower Limit
b5-35 PI Input Limit
b5-36 PI Feedback High Detection Level
b5-37 PI Feedback High Detection Time
b5-38 PI Setpoint User Display
b5-39 PI Setpoint Display Digits
b5-40 Frequency Reference Monitor Content during PI
b5-41 PI Unit Selection
b5-42 PI Output Monitor Calculation Method
b5-43 Custom PI Output Monitor Setting 1
b5-44 Custom PI Output Monitor Setting 2
b5-45 Custom PI Output Monitor Setting 3
b5-46 PI Setpoint Monitor Unit Selection
b5-47 Reverse Operation Selection 2 by PI Output
b8-01 Energy Saving Control Selection
b8-04 Energy Saving Coefficient Value
b8-05 Power Detection Filter Time
b8-06 Search Operation Voltage Limit
C1-01 Acceleration Time 1
C1-02 Deceleration Time 1
C1-03 Acceleration Time 2
C1-04 Deceleration Time 2
C1-09 Fast-Stop Time
C1-11 Accel/Decel Time Switching Frequency
C2-01 S-Curve Characteristic at Accel Start
C2-02 S-Curve Characteristic at Accel End
C4-01 Torque Compensation Gain
C4-02 Torque Compensation Primary Delay Time
C6-02 Carrier Frequency Selection
C6-03 Carrier Frequency Upper Limit
C6-04 Carrier Frequency Lower Limit
C6-05 Carrier Frequency Proportional Gain
d1-01 Frequency Reference 1
d1-02 Frequency Reference 2
d1-03 Frequency Reference 3
d1-04 Frequency Reference 4
d1-17 Jog Frequency Reference
