B.3 Parameter Table
374 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
F Through Mode
Select this setting when using the terminal in a pass-through mode. The terminal does not trigger a drive function
but can be used as digital input for the controller the drive is connected to.
184
10 Up Command
The drive accelerates when the Up command terminal closes, and decelerates when the Down command closes.
When both terminals are closed or both are open, the drive holds the frequency reference. The Up and Down
commands must always be used in conjunction with one another.
184
11 Down Command 184
12 Forward Jog
Closed: Runs forward at the Jog frequency d1-17.
185
13 Reverse Jog
Closed: Runs reverse at the Jog frequency d1-17.
185
14 Fault Reset
Closed: Resets faults if the cause is cleared and the Run command is removed.
185
15 Fast Stop (N.O.)
Closed: Decelerates at the Fast Stop time set to C1-09.
185
17 Fast Stop (N.C.)
Open: Decelerates to stop at the Fast Stop time set to C1-09.
185
18 Timer Function Input
Triggers the timer set up by parameters b4-01 and b4-02. Must be set in conjunction with the timer function output
(H2- = 12).
186
19 PI Disable
Open: PI control enabled
Closed: PI control disabled
186
1B Program Lockout
Open: Parameters cannot be edited (except for U1-01 if the reference source is assigned to the digital operator).
Closed: Parameters can be edited and saved.
186
1E Reference Sample Hold
Closed: Samples the analog frequency reference and operates the drive at that speed.
186
20 to 2F External Fault
20: N.O., Always detected, ramp to stop
21: N.C., Always detected, ramp to stop
22: N.O., During run, ramp to stop
23: N.C., During run, ramp to stop
24: N.O., Always detected, coast to stop
25: N.C., Always detected, coast to stop
26: N.O., During run, coast to stop
27: N.C., During run, coast to stop
28: N.O., Always detected, Fast Stop
29: N.C., Always detected, Fast Stop
2A: N.O., During run, Fast Stop
2B: N.C., During run, Fast Stop
2C: N.O., Always detected, alarm only (continue running)
2D: N.C., Always detected, alarm only (continue running)
2E: N.O., During run, alarm only (continue running)
2F: N.C., During run, alarm only (continue running)
186
30 PI Integral Reset
Closed: Resets the PI control integral value.
187
31 PI Integral Hold
Open: Performs integral operation.
Closed: Maintains the current PI control integral value.
187
34 PI Soft Starter Cancel
Open: PI soft starter is enabled.
Closed: Disables the PI soft starter b5-17.
187
35 PI Input Level Selection
Closed: Inverts the PI input signal
187
36 External Reference 1/2 Selection 2
Open: Run command and frequency reference source 2 (determined by b1-15 and b1-16)
Closed: Run command and frequency reference source 1 (determined by b1-01 and b1-02)
187
H1 Multi-Function Digital Input Selections
H1-
Setting
Function Description Page
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
