B.3 Parameter Table
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 375
40
Forward Run Command (2-wire
Sequence)
Open: Stop
Closed: Forward run
Note: Cannot be set together with settings 42 or 43.
187
41
Reverse Run Command (2-wire
Sequence)
Open: Stop
Closed: Reverse run
Note: Cannot be set together with settings 42 or 43.
187
42 Run Command (2-wire Sequence 2)
Open: Stop
Closed: Run
Note: Cannot be set together with settings 40 or 41.
188
43
FWD/REV Command (2-wire
Sequence 2)
Open: Forward
Closed: Reverse
Note: Determines motor direction, but does not issue a Run command. Cannot be set together with settings 40 or
41.
188
44 Offset Frequency 1
Closed: Adds d7-01 to the frequency reference.
188
45 Offset Frequency 2
Closed: Adds d7-02 to the frequency reference.
188
46 Offset Frequency 3
Closed: Adds d7-03 to the frequency reference.
188
47 Node Setup
Closed: Node setup for SI-S3 enabled.
188
50 Motor Pre-Heat 2
Closed: Triggers Motor Pre-Heat 2.
188
60 Motor Pre-Heat 1
Closed: Triggers Motor Pre-Heat 1.
188
61 External Speed Search Command 1
Closed: Activates Current Detection Speed Search from the maximum output frequency (E1-04).
188
62 External Speed Search Command 2
Closed: Activates Current Detection Speed Search from the frequency reference.
188
63 Field Weakening
Closed: The drive performs Field Weakening control as set for d6-01 and d6-02.
189
65 KEB Ride-Thru 1 (N.C.)
Open: KEB Ride-Thru 1 enabled
189
66 KEB Ride-Thru 1 (N.O.)
Closed: KEB Ride-Thru 1 enabled
189
67 Communications Test Mode
Tests the MEMOBUS/Modbus RS-422/RS-485 interface. Displays “PASS” if the test completes successfully.
189
68 High Slip Braking
Closed: Activates High Slip Braking to stop the drive.
189
69 Jog 2
Cause the drive to ramp to the Jog Frequency Reference (d1-17).
189
6A Drive Enable
Open: Drive disabled. If this input is opened during run, then the drive will stop as specified by b1-03.
Closed: Ready for operation.
189
7A KEB Ride-Thru 2 (N.C.)
Open: KEB Ride-Thru 2 enabled. Drive disregards L2-29 and performs Single Drive KEB Ride-Thru 2.
189
7B KEB Ride-Thru 2 (N.O.)
Closed: KEB Ride-Thru 2 enabled. Drive disregards L2-29 and performs Single Drive KEB Ride-Thru 2.
189
7C Short Circuit Braking (N.O.)
Closed: Short Circuit Braking enabled
189
7D Short Circuit Braking (N.C.)
Open: Short Circuit Braking enabled
189
H1 Multi-Function Digital Input Selections
H1-
Setting
Function Description Page
OLV/PMV/f
OLV/PMV/f
OLV/PMV/f
OLV/PMV/f
OLV/PMV/f
OLV/PMV/f
SIEP_C710616_35.book 375 ページ ２０１５年１１月３０日 月曜日 午後２時２分
