B.3 Parameter Table
376 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
■ H2: Multi-Function Digital Outputs
90 to 97 DriveWorksEZ Digital Inputs 1 to 8
Reserved for DWEZ input functions
190
9F DriveWorksEZ Disable
Open: DWEZ enabled
Closed: DWEZ disabled
190
No.(Addr.) Name Description Setting Page
H2-01
(40BH)
Terminals M1-M2 Function
Selection (relays)
Refer to H2 Multi-Function Digital Output Settings on page 376 for a description of setting
values.
Default: 0
Min: 0
Max: 192
190
H2-02
(40CH)
Terminals M3-M4 Function
Selection (relays)
Default: 1
Min: 0
Max: 192
190
H2-03
(40DH)
Terminals M5-M6 Function
Selection (relays)
Default: 2
Min: 0
Max: 192
190
H2-06
(437H)
Watt Hour Output Unit Selection
Outputs a 200 ms pulse signal when the watt-hour counter increases by the units selected.
0: 0.1 kWh units
1: 1 kWh units
2: 10 kWh units
3: 100 kWh units
4: 1000 kWh units
Default: 0
Min: 0
Max: 4
198
H2 Multi-Function Digital Output Settings
H2-
Setting
Function Description Page
0 During Run
Closed: A Run command is active or voltage is output.
190
1 Zero Speed
Open: Output frequency is above the minimum output frequency set in E1-09.
Closed: Output frequency is below the minimum output frequency set in E1-09.
191
2 Speed Agree 1
Closed: Output frequency equals the speed reference (plus or minus the hysteresis set to L4-02).
191
3 User-set Speed Agree 1
Closed: Output frequency and speed reference equal L4-01 (plus or minus the hysteresis set to L4-02).
191
4 Frequency Detection 1
Closed: Output frequency is less than or equal to the value in L4-01 with hysteresis determined by L4-02.
192
5 Frequency Detection 2
Closed: Output frequency is greater than or equal to the value in L4-01 with hysteresis determined by L4-02.
192
6 Drive Ready
Closed: Power up is complete and the drive is ready to accept a Run command.
193
7 DC bus Undervoltage
Closed: DC bus voltage is below the Uv trip level set in L2-05.
193
8 During Baseblock (N.O.)
Closed: Drive has entered the baseblock state (no output voltage).
193
9 Frequency Reference Source
Open: External Reference 1 or 2 supplies the frequency reference (set in b1-01 or b1-15).
Closed: Digital operator supplies the frequency reference.
193
A Run Command Source
Open: External Reference 1 or 2 supplies the Run command (set in b1-02 or b1-16).
Closed: Digital operator supplies the Run command.
193
B Torque Detection 1 (N.O.)
Closed: An overtorque or undertorque situation has been detected.
194
C Frequency Reference Loss
Closed: Analog frequency reference has been lost.
194
EFault
Closed: Fault occurred.
194
H1 Multi-Function Digital Input Selections
H1-
Setting
Function Description Page
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
