B.3 Parameter Table
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 377
F Through Mode
Set this value when using the terminal in the pass-through mode.
194
10 Minor Fault
Closed: An alarm has been triggered, or the IGBTs have reached 90% of their expected life span.
194
11 Fault Reset Command Active
Closed: A command has been entered to clear a fault via the input terminals or from the serial network.
194
12 Timer Output
Closed: Timer output.
194
13 Speed Agree 2
Closed: When drive output frequency equals the frequency reference ±L4-04.
194
14 User-set Speed Agree 2
Closed: When the drive output frequency is equal to the value in L4-03 ±L4-04.
195
15 Frequency Detection 3
Closed: When the drive output frequency is less than or equal to the value in L4-03 ±L4-04.
195
16 Frequency Detection 4
Closed: When the output frequency is greater than or equal to the value in L4-03 ±L4-04.
195
17 Torque Detection 1 (N.C.)
Open: Overtorque or undertorque has been detected.
194
1A During Reverse
Closed: Drive is running in the reverse direction.
196
1B During Baseblock (N.C.)
Open: Drive has entered the baseblock state (no output voltage).
196
1E Restart Enabled
Closed: All automatic restart is performed.
196
1F Motor Overload Alarm (oL1)
Closed: oL1 is at 90% of its trip point or greater. An oH3 situation also triggers this alarm.
196
20 Drive Overheat Pre-alarm (oH)
Closed: Heatsink temperature exceeds the parameter L8-02 value.
196
2F Maintenance Period
Closed: Cooling fan, electrolytic capacitors, IGBTs, or the soft charge bypass relay may require maintenance.
197
37 During Frequency Output
Open: Either the drive has stopped or baseblock, DC Injection Braking, or Initial Excitation is being performed.
Closed: Drive is running the motor (not in a baseblock state and DC Injection is not being performed).
197
38 Drive Enable
Closed: Multi-function input set for “Drive enable” is closed (H1- = 6A)
197
39 Watt Hour Pulse Output
Output units are determined by H2-06. Outputs a pulse every 200 ms to indicate the kWh count.
197
3A Drive Overheat Alarm (oH2)
Closed: An external device triggered an overheat warning in the drive.
197
3B
RUN Command from Option Card/
Communications
Open: Run command is not input from the MEMOBUS/Modbus communication or a Communication option.
Closed: Run command is input from the MEMOBUS/Modbus communication or a Communication option.
197
3C LOCAL/REMOTE Status
Open: REMOTE
Closed: LOCAL
197
3D During Speed Search
Closed: Speed Search is being executed.
197
3E PI Feedback Low
Closed: PI feedback level is too low.
197
3F PI Feedback High
Closed: The PI feedback level is too high.
198
4A During KEB Operation
Closed: KEB Ride-Thru is being performed.
198
H2 Multi-Function Digital Output Settings
H2-
Setting
Function Description Page
