7.3 Periodic Maintenance
302 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
Table 7.5 Maintenance Alarms
■ Related Drive Parameters
Parameters o4-03, o4-05, o4-07, and o4-09 can be used to reset a Maintenance Monitor back to zero after a specific
component has been replaced. Refer to Parameter Table on page 360 for details on parameter settings.
NOTICE: If these parameters are not reset after the corresponding parts have been replaced, the Maintenance Monitor function will
continue to count down the performance life from the value that was reached with the old part. If the Maintenance Monitor is not reset,
the drive will not have the correct value of the performance life for the new component.
Alarm Display Function Corrective Action
<1>
<1> This alarm message will be output only if the Maintenance Monitor function is assigned to one of the digital outputs (H2- = 2F). The alarm
will also trigger a digital output that is programmed for alarm indication (H2- = 10).
<2> This alarm message will always be output, even if the Maintenance Monitor function is not assigned to any of the digital outputs (H2- =
2F). The alarm will also trigger a digital output that is programmed for alarm indication (H2- = 10).
LT-1 The cooling fans have reached 90% of their designated life time. Replace the cooling fan.
<1>
LT-2
The DC bus capacitors have reached 90% of their designated life
time.
Contact a Yaskawa representative or the nearest Yaskawa sales
office on possible drive replacement.
<1>
LT-3
The DC bus charge circuit has reached 90% of its designated life
time.
Contact a Yaskawa representative or the nearest Yaskawa sales
office on possible drive replacement
<1>
LT-4 The IGBT’s have reached 50% of their designated life time. Check the load, carrier frequency, and output frequency.
<2>
TrPC The IGBT’s have reached 90% of their designated life time.
Contact a Yaskawa representative or the nearest Yaskawa sales
office on possible drive replacement.
