B.7 Parameters that Change with the Motor Code Selection
Parameter List
B
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 407
Table B.12 200 V, 1450 r/min Type YASKAWA SSR1 Series IPM Motor
No. Name Unit Default Settings
E5-01
Motor Code Selection − 1302 1303 1305 1306 1308 130A 130B 130D
Voltage Class V 200 200 200 200 200 200 200 200
Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11
Rated Speed r/min 1450 1450 1450 1450 1450 1450 1450 1450
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0
E5-03 Motor Rated Current A 1.88 3.13 5.63 8.33 14.17 20.63 27.71 39.6
E5-04Number of Motor Poles –66666666
E5-05 Motor Stator Resistance (r1) Ω 3.190 1.940 1.206 0.665 0.341 0.252 0.184 0.099
E5-06 Motor d-Axis Inductance (Ld) mH 32.15 26.12 14.72 12.27 8.27 6.49 6.91 4.07
E5-07 Motor q-Axis Inductance (Lq) mH 41.74 34.30 20.15 14.77 9.81 7.74 7.66 4.65
E5-09 Motor Induction Voltage Constant 1 (Ke) mVs/rad 264.3 269.6 284.3 287.1 284.5 298.0 335.0 303.9
E5-24 Motor Induction Voltage Constant 2 (Ke) mV/(r/min) 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum Output Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-05 Maximum Voltage V 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-09 Minimum Output Frequency Hz 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6
L3-24
Motor Acceleration Time for Inertia
Calculations
s 0.098 0.071 0.066 0.087 0.085 0.072 0.084 0.096
n8-49
d-Axis Current for High Efficiency
Control (OLV/PM)
% -6.6 -10.9 -13.5 -9.0 -9.5 -10.1 -6.0 -9.3
No. Name Unit Default Settings
E5-01
Motor Code Selection − 130E 130F 1310 1312 1313 1314 1315
Voltage Class V 200 200 200 200 200 200 200
Rated Power kW15182230374555
Rated Speed r/min 1450 1450 1450 1450 1450 1450 1450
E5-02 Motor Rated Power kW 15.00 18.50 22.00 30.00 37.00 45.00 55.00
E5-03 Motor Rated Current A 55.5 65.6 75.1 105.2 126.0 153.1 186.5
E5-04Number of Motor Poles –6666666
E5-05 Motor Stator Resistance (r1) Ω 0.075 0.057 0.041 0.034 0.023 0.015 0.012
E5-06 Motor d-Axis Inductance (Ld) mH 3.29 2.53 1.98 1.75 1.48 1.04 0.87
E5-07 Motor q-Axis Inductance (Lq) mH 3.84 3.01 2.60 2.17 1.70 1.31 1.10
E5-09 Motor Induction Voltage Constant 1 (Ke) mVs/rad 311.2 300.9 327.7 354.2 369.6 351.6 374.7
E5-24 Motor Induction Voltage Constant 2 (Ke) mV/(r/min) 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum Output Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-05 Maximum Voltage V 190.0 190.0 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-09 Minimum Output Frequency Hz 3.6 3.6 3.6 3.6 3.6 3.6 3.6
L3-24
Motor Acceleration Time for Inertia
Calculations
s 0.085 0.080 0.122 0.108 0.161 0.160 0.175
n8-49
d-Axis Current for High Efficiency
Control (OLV/PM)
% -10.7 -13.2 -15.7 -11.5 -7.0 -11.8 -10.2
