4
Mounting and Wiring
4.5.2
217IF-01 Module
4-66
( 4 ) Module Connection Examples
[ a ] PORT Connector Connections
For information on how to connect the PORT connector, refer to 4.5.1 ( 4 ) [ a ] PORT Connector
Connections on page 4-61.
[ b ] RS422/485 Connections
îš„
RS422 Wiring
To Controller or
other terminal
ON
217IF-01
ERR
TRXSTRX
RUN
TEST
INIT
485
ONOFF
PORT
RS422/485
DC24V
DC 0V
MP2300
YASKAWA
TEST
Option
Option
RDY
ALM
TX
RUN
ERR
BAT
MON
CNFG
INT
SUP
STOP
SW1
OFF ON
BATTERY
CPU I/O
M-I/II
1
2
11
3
4
7
14
RS422/485
3
RX+
4
RX-
7
RXR
1
TX+
2
TX-
11
TXR
14
GND
FG
TX+
TX-
TXR
RX +
RX-
RXR
GND
RS422/485
Connector
shell
1
2
11
3
4
7
14
RS422/485
TX+
TX-
TXR
RX +
RX-
RXR
GND
Connector
shell
Connector
shell
Remote station
The following connections apply if the
remote station is another 217IF-01 Module.
