YASKAWA JEPMC-MP2300-Y Series User Manual

2
System Startup and Sample Programs
2.1.5
Starting and Preparing MPE720
2-16
2.
Enter a group folder name of up to 8 characters and click the OK Button.
A new group folder will be created. Double-click (root) or click to display the entered
group folder name.
( 4 ) Creating Order Folders (Required)
In the File Manager Window, create an Order Folder for storing Controller Folders.
1.
Right-click (root) or the Group Folder in which the Order Folder is to be created and
select New - Order Folder from the pop-up menu.
The Make New Folder Dialog Box will appear.
Group folders, order folders, and PLC folders form part
of a directory tree, as shown in the figure to the left.
Programs created using MPE720 are saved to PLC
folders.
MPE720 cannot create programs if no PLC folder
exists. PLC folders cannot be created if no order folder
exists. For this reason, always create an order folder and
PLC folder. Creating group folders is optional.
Group
folders
Order
folders
Controller
folders
■
Group, Order, and PLC folders
