Gen II User Manual
2-3 – Analyzer Description Chapter 2 Revision 2.1, April
The brightness key is located below the [F4] key. This key is fully functional for all phases of
operation when the analyzer is powered. There are eight levels of brightness. Each key press will
produce an incremental increase in the screen’s brightness. Once the highest level of brightness
has been reached, the next key press will return the screen to the first brightness level.
The Day / Night key, when pressed once, cycles the display between Day and Night mode. Day
mode is enabled by default and makes the screen easier to see in daylight conditions. Night mode
is designed to increase the contrast between the background and text or graphics to make reading
the display easier during dark conditions.
The [OK] key is pressed to accept data or a menu selection and set that selection into motion.
The key is used in survey and balance procedures to proceed to the next step.
Pressing the Help key allows you to access guidance and/or examples of information that can be
entered into the current field. When viewing the Main Menu, pressing the Help key will display
the Version screen as shown in the image at the beginning of this chapter.
