Gen II User Manual
13-30 – Transient Vibration Survey Chapter 13 Revision 4.10, Apr 20
13.1.10. – Storing Data
Anytime the spectrum is displayed on screen you may press [OK] to terminate data acquisition.
The analyzer then displays the screen shown below.
If a single condition was configured in paragraph 13.1.1.3, the “Shut Down Engines” screen
shown on the following page will be displayed.
If multiple conditions were configured in paragraph 13.1.1.3, the “Select Aircraft Condition”
banner screen is again displayed as shown in the following figure. Notice that the condition for
which you just collected and stored data now has an “X” immediately to the left of the defined
condition. This alerts the user that data has been collected and stored for this condition. This does
not preclude you from selecting and acquiring new data for this condition. However, if you
choose to store the data, the previously stored data will be written over and may not be
recovered.
