Gen II User Manual
13-31 – Transient Vibration Survey Chapter 13 Revision 4.10, Apr 20
At this point you may select a new condition and repeat procedures starting from paragraph
13.1.7 until all required data are collected. If you would like to exit the job with the ability to
resume it later, you can press the [F1] “Pause Job” key. This will cause the following screen to
be displayed. If you are finished collecting data, shut down the engine(s) per the manual
instructions and use the [F5] “Continue” key to mark the job complete and store it to memory.
From the “Select Condition” screen, to quit the job and return to the “Transient Vibration
Surveys” banner screen, press [F5] for “Quit Job.”
13.2. – Resume Job
The features in this section are common among all jobs. Because of this, they are contained in
Chapter 3, “Using the Gen II Analyzer”.
