Chapter 23
Equipment and Accessory Setup and
Troubleshooting
(Revision 4.01, Apr 2020)
The information in this chapter is provided to assist you in avoiding some of the common pitfalls
associated with setting up and using the various accessories, cables and sensors required for
performing routine balance or vibration survey jobs with the Gen II Analyzers.
23.1. – Battery Charger and Battery
WARNING
Use only the ACES-supplied charger. Non-ACES Supplied chargers are not recommended due to
operational limits and possible damage that may be incurred.
CAUTION
The charger is built for indoor use only. Do not expose the charger to the elements.
CAUTION
Power requirements must be determined on an individual basis. Operating the analyzer with the
battery charger connected can affect the accuracy of the acquired readings. The analyzer was not
intended to be operated during the charging process.
23.1.1. – Battery Specifications and Typical Use
The primary power source for the analyzer is its internal 7200mAH lithium ion battery. Do not
attempt to replace the battery yourself because of the possibility of injury to yourself or damage
to the analyzer. There are no usable-serviceable parts inside the analyzer.
