ACES SYSTEMS Cobra II User Manual

Gen II User Manual
19-10 – Monitor Overall Chapter 19 Revision 2.10, Apr 2020
above and when presented with the choice, press either the [F1] “Normal” or [F3]
“None” key and the multiple cursors will be replaced by your selection.
 Pressing the [F3] “None” key will remove any cursor currently displayed on
screen. The three boxes above the [F1], [F2], [F4] and [F5] keys will return to
“Options,” “Resume,” “Overall” and “Restart” respectively. If no cursor is
displayed when pressing this key, only the box nomenclature will change.
 Pressing the [F2] “X scale” or [F3] “Y scale” keys will change the [F1], [F2], [F3], and
[F5] boxes to read “Expand,” “Default,” “Shrink” and “Cancel” respectively as shown in
the following figure.
 Pressing the [F1] “Expand” key will expand the X or Y scale of the spectra, in
effect enlarging the viewing area. You might think of this function as a “Zoom
Out” feature. The center of the Expanded view will be the position of the cursor
