7 — ONT equipment layout
7-4 July 2008 Alcatel-Lucent 7342 ISAM FTTU ONT R04.05.06
ONT Product Information Manual Edition 01 3FE 51892 AAAA TCZZA
(11)
The O-24121V-A variant supports RF video while the O-24120V-A variant does not support RF video.
(12)
The O-24121G-A variant supports RF video while the O-24120G-A variant does not support RF video.
(13)
The M-300-A comes in two variants. See the modular ONT unit data sheer for information about the differences.
(14)
The M-300-A part number 3FE 50533 AB has an OptiTap connector.
(15)
The S-840V-A service plug-in unit installs in the M-300-A ONT and provides the M-300-A with POTS and VDSL2 ports. Up to
three S-840V-A units can install in an M-300-A ONT.
Table 7-2 shows the maximum number of ONTs supported on a given PON when all
ONTs are of the same type.
Table 7-2 Maximum ONT connections per PON
Note
(1)
All ONTs connected to the PON are assumed to be of the same type.
7.4 Indoor ONT connections and physical components
The following sections describe the different ONT connections and physical
components.
I-020E-B, I-020E-H, I-020G-F, and I-020G-G connections and
components
The I-020E-B, I-020G-F, I-020G-G, and I-020E-H ONTs are for indoor deployment
and can be installed vertically or horizontally. Connections to the SC/APC and RJ-45
ports are on the outside of the ONT.
Figure 7-1 shows the indoor ONT physical connections for the I-020E-B and
I-020E-H.
ONT Maximum ONTs per PON
(1)
Indoor ONT 64
Outdoor ONT (single residence and SOHO) 64
Outdoor ONT (LP MDU) 8
Modular ONT 8
Business ONT 64
