Alcatel-Lucent 7342 - 30 - O-24121 G-A and O-24120 G-A Unit Data Sheet; Identification

24 — O-210E-B and O-211E-B unit data sheet
24-2 July 2008 Alcatel-Lucent 7342 ISAM FTTU ONT R04.05.06
ONT Product Information Manual Edition 01 3FE 51892 AAAA TCZZA
24.1 Identification
Table 24-1 provides identification information about the outdoor ONTs.
Table 24-1 Identification of outdoor ONTs
Note
(1)
See the 7342 ISAM FTTU ONT Planning and Ordering guide for product identification information.
24.2 General description
The outdoor ONT provides the subscriber interface for the 7342 ISAM FTTU. The
ONT terminates the PON interface and converts it to user interfaces that directly
connect to subscriber devices. The ONT is compatible with all existing subscriber
equipment, including analog phones with both tone and rotary dial capabilities,
cordless phones, modems, fax machines, and caller ID boxes (Type I, Type II, and
Type III).
The outdoor ONT provides the following functions:
• network demarcation for all services
• voice interworking function from the analog POTS lines to the VoIP/Ethernet
layers
• interworking functions between the GEM and Ethernet layers
• interworking functions between the PON optical overlay and the RF video
interface
• mux and demux functions to the PON
• optical to electrical conversion
Part number Mnemonic
(1)
Description CLEI CPR ECI/Bar
code
3FE 50683 AF
3FE 50683 AP
O-210E-B GPON O-series ONT unit, version B, 2 POTS,
1 Ethernet interface for both data and IP
video, craft interface, and SC/APC
interface
BVM3J00CRA
BVM4510DRA
209106
210867
449273
453984
3FE 50683 AB
3FE 50683 AK
3FE 50683 AU
O-210E-B GPON O-series ONT unit, version B, 2 POTS,
1 Ethernet interface for both data and IP
video, and SC/APC interface. The AU
variant has optics that support RSSI.
BVM3E00CRA
BVM4110DRA
—
209102
210862
—
449269
453979
—
3FE 50683 AH
3FE 50683 AS
O-210E-B GPON O-series ONT unit, version B, 2 POTS,
1 Ethernet interface for both data and IP
video, craft interface, and OptiTap
interface
—
BVM4710DRA
—
210869
—
453986
3FE 50683 AC
3FE 50683 AL
O-211E-B GPON O-series ONT unit, version B, 2 POTS,
1 Ethernet interface for both data and IP
video, RF video, EPC jumper for +12V PoE,
craft interfaces, and SC/APC interface
BVM3F00CRA
BVM4210DRA
209103
210864
449270
453981
3FE 50683 AG
3FE 50683 AR
O-211E-B GPON O-series ONT unit, version B, 2 POTS,
1 Ethernet interface for both data and IP
video, RF video, EPC jumper for +12V PoE,
craft interface, and OptiTap interface
BVM3K00CRA
BVM4610DRA
209107
210868
449274
453985
