10 — ONT technical specifications
10-28 July 2008 Alcatel-Lucent 7342 ISAM FTTU ONT R04.05.06
ONT Product Information Manual Edition 01 3FE 51892 AAAA TCZZA
Table 10-36 Power consumption specifications (I-211M-D)
Power and alarm connections are internal to the unit.
Indoor ONT (I-211M-G)
Table 10-37 provides the power consumption specifications for the I-211M-G ONT.
Table 10-37 Power consumption specifications (I-211M-G)
Power and alarm connections are internal to the unit.
SOHO outdoor ONT
All O-8xxx-x ONTs require 48 V DC input power supplies. See the appropriate ONT
data sheet for specific UPS support. For the SOHO outdoor ONT, Alcatel-Lucent
recommends the use of a listed DC power supply with LPS or Class 2 outputs,
suitably approved and rated for the application. Outputs at SELV/LPS levels rated
for 48 V dc, 3.124 A are required.
The UPSs that are Alcatel-Lucent approved for use with the SOHO include the
following:
• FlexNet FMPS-150 W UPS
• CyberPower CyberShield CS 50 UPS
Table 10-38 lists the measured power consumption values for the O-821 G-D and
O-820G-D SOHO outdoor ONT.
Power consumption Specification
Peak power consumption Not exceeding 15.0 W with all services active (2 POTS
on-hook and 1 Ethernet for data operational)
Power consumption with all service
interfaces idle
Not exceeding 9.0 W
Power consumption Specification
Peak power consumption Not exceeding 15.0 W with all services active (2 POTS
on-hook and 1 Ethernet for data operational)
Power consumption with all service
interfaces idle
Not exceeding 9.0 W
Note — The O-821M-E can only use the FlexNet FMPS-150 W
48 V dc UPS.
