14.1 Identification
Table 14-1 provides identification information about the indoor ONTs.
Table 14-1 Identification of the indoor ONT
Note
(1)
See the 7342 ISAM FTTU ONT Planning and Ordering guide for product identification information, including additional
AC/DC power converter cabling information.
14.2 General description
The indoor ONT provides the subscriber interface for the 7342 ISAM FTTU. The
ONT terminates the PON interface and converts it to user interfaces that directly
connect to subscriber devices. The ONT is compatible with all existing subscriber
equipment.
The indoor ONT provides the following functions:
• network demarcation for all services
• interworking functions between the GEM and Ethernet layers
• mux and demux functions to the PON
• optical to electrical conversion
14.3 ONT hardware and software features
Table 14-2 provides a list of hardware based features for the I-020E-B and the
I-020E-H.
Part number Mnemonic
(1)
Description CLEI CPR ECI/Bar
code
3FE 28683 AB I-020E-B GPON I-series ONT, version B, asymmetric,
2 Ethernet, 28 dB variant (available in the
ETSI market)
———
3FE 28683 AC I-020E-H GPON I-series ONT, version H, asymmetric,
2 Ethernet, 28 dB variant (available in the
ETSI market)
———
3FE 28683 AD I-020E-H GPON I-series ONT, version H, asymmetric,
2 Ethernet, 28 dB variant (available in the
ETSI market) with a later version of the SoC.
———
1AF 01226 AK — The AC/DC power converter converts 120 V
ac to 12 V dc and installs inside the
customer residence. An Alcatel-Lucent
approved power cable is required.
———
1AB 07676
0009
(1)
— Cable, AS 3112 plug to IEC 60320 C13
connector, 3-conductor, 10 A, 250 V ac,
1.78 m, black (Australia/China)
———
