7 — ONT equipment layout
7-36 July 2008 Alcatel-Lucent 7342 ISAM FTTU ONT R04.05.06
ONT Product Information Manual Edition 01 3FE 51892 AAAA TCZZA
Figure 7-27 Soho or business ONT showing inner covers
B-8112-A and B-8102-A connections
Figure 7-28 shows the B-8112-A business ONT physical connections. The
B-8102-A has exactly the same layout and connectors, except that the RF video port
is not available.
TELCO ACCESS
PWR
LINE
1
BTRY
FAIL
VIDEO
DATA
NTWK
MGMT
INTF
POTS
LINE
2
LINE
3
LINE
4
LINE
5
LINE
6
LINE
7
LINE
8
TRTRTRTR TRTRTRTR
1
2
3
4
T
R
5
6
7
INPUT RATING: DC
45V 55V 1.0A
THIS DEVICE IS INTEDED TO BE
ATTACHED TO A RECEIVER THAT IS
NOT USED TO RECEIVE OVER-THE0AIR
BROADCAST SIGNALS. CONNECTION OF
THIS DEVICE IN ANY OTHER FASHION
MAY CAUSE HARMFUL INTERFERENCE
TO RADIO COMMUNICATION AND IS
IN VIOLATION OF THE FCC RULES,
PART 15.
VIDEO
TELCO ACCESS
SF EQPT
DS1
DS2
1
SF EQPT
2
1
MODE LINK
ETHERNET
Power connecto
r
cover
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This Class A digital apparatus complies with Canadian ICES-003. Cet appareil
numerique de la class A est conforme a la norme NMB-003 du Canada
Tested to Comply
with FCC Standards
FOR HOME OR OFFICE USE
COMMUNICATION SERVICE EQUIPMENT
US LISTED
27FY
Type 3R Enclosure - Rainproof
CAUTION
This Assembly Contains Electrostatic Sensitive Devices
WARNING
c
®
1896
1
Tamper-resistant
bolt
Tamper-resistant
bolt
Optical
connector
area cover
