41 — Delta DUPS-1232A UPS unit data sheet
Alcatel-Lucent 7342 ISAM FTTU ONT R04.05.06 July 2008 41-5
3FE 51892 AAAA TCZZA Edition 01 ONT Product Information Manual
(2)
To restore the alarm, press the button and hold down for 3 to 5 seconds.
41.6 Alarms
Audible alarms alert the user of abnormal or service-effecting conditions on the
Delta DUPS-1232A UPS.
Table 41-4 describes battery backup audio alarms and signal information.
Table 41-4 Battery backup audio alarm and condition
41.7 Connections
The Delta DUPS-1232A UPS has the following connections:
• input connector/plug: IEC 320/C5, NEMA 1-15P, 3-prong plug/pass thru
• cord length: 8.0 ft (2.44 m)
• output connector: 3.5 mm (0.14 inch) 7-position screw terminal connectors
• auxiliary input power connector: DC jack, 3.5 mm (0.14 inch) OD return, 1.3 mm
(0.05 inch) ID positive center
Figure 41-2 shows the UPS output power and alarm connector.
Alarm Condition Alarm audio
ON BATTERY (or AC
Fail)
The on-battery alarm indicates that the UPS is operating
using the battery backup.
One beep at time of
power loss
REPLACE BATTERY The replace-battery alarm indicates that the battery has
failed the self test.
Replace the battery if there is a failure.
One beep every 15
minutes
BATTERY MISSING The battery-missing alarm indicates that the battery is
missing or there is an open circuit.
None
BATTERY LOW The low-battery alarm indicates that the battery charger
has fallen below 45% capacity when operating from the
battery.
Four beeps every
minute
