39 — CyberPower CyberShield CS 50 UPS unit data sheet
39-2 July 2008 Alcatel-Lucent 7342 ISAM FTTU ONT R04.05.06
ONT Product Information Manual Edition 01 3FE 51892 AAAA TCZZA
39.1 Identification
Table 39-1 provides identification information about the ONT power supply with
battery backup from CyberPower Systems, Inc.
Table 39-1 Identification of the UPS
39.2 Features and application notes
The UPS provides:
• 50 W power capability with 48 V dc on battery output voltage
• input voltage range of 85 to 264 V ac at 40 to 70 Hz frequency range
• sealed, maintenance-free, lead-acid battery (12 V 20 Ah)
• battery diagnostic LEDs, and battery status outputs
The UPS meets:
• UL 60950-1, CSA C22.2 No. 60950-1, NEBS Level 1 and 3 (GR1089 and
GR63), FCC Part 15 Class B
39.3 General description
The UPS converts ac input power (87 to 264 V ac) to dc power (50 W, 48 V dc). The
battery provides up to 8 h of backup power for the lifeline POTS service, depending
on environmental conditions and load.
An audible alarm is available on the UPS to monitor the operational status of the
backup battery. LED status indicators also provide the service personnel with
information on the status of the ac input, dc output, and battery.
39.4 Status LEDs
Three indicator LEDs are present on the front of the UPS. Each LED is labeled with
an icon. The LEDs and the icons, with their meanings, are shown in Table 39-2. The
operating mode can be determined by the state of these LEDs.
Part Number Description
— CyberPower CyberShield CS 50 50 W, 48V ac UPS.
Note — If the plug is not the correct type, please contact the local
Alcatel-Lucent support group for a recommended adapter.
