7 — ONT equipment layout

7-40 July 2008 Alcatel-Lucent 7342 ISAM FTTU ONT R04.05.06

ONT Product Information Manual Edition 01 3FE 51892 AAAA TCZZA

Note

(1)

This interface is not supported on all ONT units. See the business ONT UDS and the SOHO outdoor

ONT UDS for details.

7.10 Cable storage compartments

The outdoor, SOHO, and business ONTs support cable storage compartments. The

following sections describe these compartments.

3EM 17661 AB compartment

Figure 7-31 shows the cable storage compartment.

Power and alarm

connections

Terminals are provided to connect an external –48 V dc UPS to the business

ONT with support for battery alarm connections.

RF video and MoCA

connection

(1)

This connection is provided through the F-type connector for CATV, MoCA

data and IPTV services. Each business ONT supports one RF video connection.

Standard 75 Ω coaxial cable can be used, including: RG59, RG6, or Series 7

coaxial cable.

Connection Function

(2 of 2)
