39 — CyberPower CyberShield CS 50 UPS unit data sheet
39-4 July 2008 Alcatel-Lucent 7342 ISAM FTTU ONT R04.05.06
ONT Product Information Manual Edition 01 3FE 51892 AAAA TCZZA
Table 39-4 Buzzer On/Off switch
39.6 Connections
The UPS has the following:
• input connector: NEMA 1-15P plug
• cord length: 8.0 ft (2.44 m)
• output connector: supplied with UPS
Table 39-5 describes the UPS output pinouts.
Table 39-5 CyberShield CS 50 power wiring chart
39.7 Specifications
The following specifications apply to the CyberPower CyberShield CS 50 UPS.
Physical description
The UPS has the following physical description:
• height: 11.75 in. (298 mm)
• width: 11 in. (279 mm)
• depth: 4 in. (101 mm)
• weight: 17.5 lb (7.9 kg)
Setting Description
ON The alarm buzzer emits a long beep in response to a utility
failure or short beep when the battery is low on power.
OFF The alarm will not sound.
The default setting.
Wire color Signal
Red (RED) 48 V
Black (BLK) 48 V RTN
Green (GRN) SIG RTN
Slate (SLT) ON BATTERY
Brown (BRN) REPLACE BATTERY
Blue (BLU) BATTERY MISSING
Orange (ORN) LOW BATTERY
