18 — I-211M-D unit data sheet
18-2 July 2008 Alcatel-Lucent 7342 ISAM FTTU ONT R04.05.06
ONT Product Information Manual Edition 01 3FE 51892 AAAA TCZZA
18.1 Identification
Table 18-1 provides identification information about the I-211M-D ONT.
Table 18-1 Identification information about I-211M-D ONT
Note
(1)
See the 7342 ISAM FTTU ONT Planning and Ordering guide for product identification information.
18.2 General description
The indoor ONT provides the subscriber interface for the 7342 ISAM FTTU. The
ONT terminates the PON interface and converts it to user interfaces that directly
connect to subscriber devices. The ONT is compatible with all existing subscriber
equipment, including analog phones with both tone and rotary dial capabilities,
cordless phones, modems, fax machines, and caller ID boxes (Type I, Type II, and
Type III).
The I-211M-D ONT meets or exceeds the specifications of MoCA 1.0 as determined
by the Multimedia over Coax Alliance (MoCA).
Part number Mnemonic
(1)
Description CLEI CPR ECI/Bar
code
3FE 51307 AA
(customer-spec
ific logo on
door)
I-211M-D GPON I-series ONT unit, version D, 2 POTS
interfaces, 1 10/100/1000 BASE-T Gigabit
Ethernet interface, 1 RF video, and 1 MoCA
interface.
The 3FE 51307 AA has an OptiTap connector
while the 3FE 51307 BA variant has a
SC/APC connector. The 3FE 51307 CA
variant is installed mounted in wall.
The 3FE 51307 BA comes equipped with a
fiber strength member clamp.
BVM5W00CRA 211340 454724
3FE 51307 BA
(without
customer-speci
fic logo on
door)
———
3FE 51307 CA
(customer-spec
ific logo on
door)
———
UPS (included
with the ONTs
listed above
and not
orderable
separately)
— The Delta 38 W, 12 V dc OPSU/BBU is a
power supply equipped with a backup
battery. The OPSU/BBU is located at a
subscriber location and converts ac input
(90 to 135 V ac, 47 to 63Hz) to a dc output
(47.5 to 52 V dc). The backup battery
provides up to 8 hours of temporary power
in the event of power loss.
The 3FE 51307 AA comes equipped with an
extra amount of OPSU to BBU cable for
remote OPSU installations while the 3FE
51307 BA does not.
———
PX12072
PXL12072
PWL12V7
— Batteries supplied by GS Yuasa International
Ltd. approved for use with the I-211M-D
ONT.
———
