26 — O-211M-R unit data sheet
Alcatel-Lucent 7342 ISAM FTTU ONT R04.05.06 July 2008 26-3
3FE 51892 AAAA TCZZA Edition 01 ONT Product Information Manual
Table 26-2 ONT hardware features
Table 26-3 describes software based features for the O-211M-R outdoor ONT.
Features Chapter Reference
Functional description ONT overview Outdoor ONT
Functional blocks SoC based ONT functional blocks System on a Chip (SoC) technology
SoC ONTs with RF video subsystem
SoC ONTs with MoCA subsystem
Connections ONT equipment layout Connections
Outdoor ONT connections and components
Service interface
specifications
ONT technical specifications Ethernet interface specifications
POTS interface specifications
RF video interface specifications
• Coaxial connectivity in the home and design
guidelines
• Configuration recommendations
• 14 dBmV RF video receivers
Physical description
(height, width, depth,
weight)
ONT technical specifications Outdoor ONT
Physical security features ONT software and security features Physical ONT security
LEDs ONT LEDs Outdoor ONT LEDs
Data flow characteristics ONT overview Outdoor ONT
GPON wavelength ONT overview Outdoor ONT
Optical budget ONT technical specifications ONT optical budget
Power consumption ONT technical specifications Power consumption
Location and installation
options
ONT equipment layout Location options
Temperature and humidity
range
ONT technical specifications Environmental requirements
Fiber storage
compartment
ONT equipment layout 3EM 17661 AB compartment
3EM 17661 AC compartment
3EM 20293 AA compartment
ONT activation methods ONT software and security features ONT activation methods
SLID entry via craft
interface
ONT software and security features —
SLID entry via POTS
interface
ONT software and security features SLID entry via first POTS port
SLID entry via Ethernet
interface
——
Supported UPS UPS unit data sheets CyberPower CyberShield CS 24 UPS unit data sheet
