9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. II-3-31
Off INU off-line or ODU transmit muted
Green RAC is online with transmit or receive active
1
Red No receive signal from the ODU
Status LED Status LED provides indications of:
Off INU power off
Green Normal operation
Orange
flashing
Configuration not supported, or software / hardware
incompatible
2
Red Critical RAC or ODU alarm
3
3 XPIC In/Out
connectors
SMB type for XPIC cross-connect cables
4 ODU connector SMA type for ODU jumper cable connection
1. The transmit active or receive active criteria supports all protected configurations where one RAC is transmitting and receiving
and the other receiving only.
2. Includes situations where the slot configuration does not support the plug-in, or the plug-in requires a later/different version of
system software.
3. Includes alarm situations caused by component or power supply failure and transmit or receive path failure.
