9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. IV-3-11
16. Repeat steps 2 to 16 for the other end of the link.
17. Record the RSL at both ends of the link and check values against the expected
RSLs in the installation datapack.
18. Complete a BER test. Loopbacks are available within CT under Diagnostics
> System/Controls. For details refer to System/Controls, Volume IV,
Chapter 15.
19. For details, refer to System/Controls on page 15-43.
20. Configuration: As Built
21. Complete capture of commissioning data.
The link is now ready for use.
Configuration Changes to An Existing
Installation
Where changes are to be made to an existing installation/configuration, follow
the configuration process relevant to the required change(s) in the preceding
section, Procedure Overview for a New Installation. However before doing so
you may wish to save the current configuration for subsequent restoration
(rollback) in the event of difficulties with the new configuration:
• Within CT select File > Backup to save a current Node/Terminal configuration
(as set by the most recent Send action) to a user-selectable folder on your PC.
• Select File > Restore to prompt for selection of the saved configuration from
your PC, and its loading back into a Node/Terminal. Follow the on-screen
prompts to complete the restoration process.
9500 MXC Node 9500 MXC Terminal
Select Installation > As-Built Report to capture
configuration and other site/installation data for
appending to a final commissioning report.
Refer to Reports on page 5-1 for details.
Select
Installation > As-Built Report to capture
configuration and other site/installation data for appending to
a final commissioning report.
Refer to Reports on page 5-1 for details.
To Next Page
