Chapter 1. 9500 MXC CT Introduction
This chapter introduces 9500 MXC CT features and functions.
The main topics are:
• 9500 MXC CT Screens on page 1-1
• 9500 MXC CT Symbols on page 1-3
• 9500 MXC CT Naming Conventions on page 1-8
• 9500 MXC CT Auto Version on page 1-8
9500 MXC CT Screens
All 9500 MXC CT (CT) screens have the look and feel of a Windows
environment. For an example screen.
Access to on-screen features and commands is provided by mouse click and/or
quick-access key commands.
The Tool Bar, Menu Bar, and Status Bar are present on all screens.
The Menu Bar provides direct navigation to main areas of user interest. Clicking
on a Menu brings up a sub-menu that provides direct access to relevant screens
and commands.
The Status bar shows the site name, terminal name, and an IP address, plus
problem graphics, and a system alarm/severity icon, which provide a status
summary for the Node/Terminal. To view which module or modules are creating
an alarm, refer to the System Summary screen.
For an Ethernet connection, the IP address displayed is the Ethernet address of
the Node/Terminal. For a V.24 connection, the IP address is the default
connection address.
