9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. IV-15-7
to Node and Terminal Plug-ins on page 7-1.
Event Browser
The Event Browser, in Figure 15-2, provides a real time view of all events, both
active and cleared, for the selected 9500 MXC Node or Terminal. The browser
has a nominal capacity of 5000 events, after which time new events replace
earliest events on a one-for-one basis.
See Event Browser Screen Description on page 15-9 and Event Browser
Navigation on page 15-9.
Figure 15-2. Event Browser Screen for a 9500 MXC Node
Changes to configuration are limited to detected and accepted plug-ins. CT does
not allow configuration of expected plug-ins (a Plug-in must be installed and
accepted).
Item Description
1 Event Box.
2
3
4
5
6
7
8
9
10
1
