Chapter 2. 9500 MXC Terminals
Vol. II-2-2 Alcatel-Lucent
Capacity and Bandwidth Options
Depending on the IDU and its capacity/bandwidth options, modulation rates are
programmed for QPSK, 16QAM, 32QAM, 64QAM, or 128QAM:
• Table 2-1 lists the ETSI capacity, modulation, and bandwidth options for IDU
20x. Table 2-2 lists the options for North American (ANSI) Common Carrier.
• Table Table 2-3 on page 2-3 lists ETSI and ANSI capacity, modulation, and
bandwidth options for IDU 155o.
Table 2-1. IDU 20x ETSI System Options
Please check the Product Release Notes to confirm the availability of modem profiles.
ETSI band plans for 55/56 MHz channeling and ANSI band plans for 50 Mhz
channeling are generally restricted to bands 18 GHz and higher.
Capacity Channel
Bandwidth
Modulation
5xE1 7 MHz QPSK
10xE1 13.75 / 14 MHz QPSK
20xE1 27.5 / 28 MHz QPSK
5xE1 3.5 MHz 16QAM
10xE1 7 MHz 16QAM
16xE1 7 MHz 64 QAM
20xE1 13.75 / 14 MHz 16 QAM
32xE1 13.75 / 14 MHz 64 QAM
40xE1 27.5 / 28 MHz 16 QAM
