Chapter 9. Circuits
Vol. IV-9-6 Alcatel-Lucent
DAC ES/GE Circuit Configuration Screen
Figure 9-4 shows DAC ES port-to-port connections for the node illustrated in
Figure 9-2.
For a DAC GE configured with an E1 or DS1 channel type, its Circuits screen
function is identical to a DAC ES.
For a DAC GE configured with an STM1 channel type the same circuit functions
apply, though for STM1 circuits.
3 To establish a new connection from the From selection to the To selection
click Apply.
• For a new node (no circuits allocated) bulk trib connection options are
presented on initial selection.
• Where only some of the capacity (number of ports) is to be connected,
click and select from the Port - Port menu boxes, which provide a
port-by-port selection. Click Apply to set the first connection, and
continue to click Apply to establish subsequent connections.
• Similarly, where a new set of connections is to be established, from a
Link or Data that has already had ports allocated, use the Port - Port
menus to set the start of the port numbering for From and To, and click,
and continue to click Apply to complete the connection assignment.
• To view an check individual port-to-port assignments click the relevant
toggle down.
• Red text indicates a port is allocated. Black indicates it is unallocated.
• Existing port-to-port connections (red) can be changed by selecting and
re-connecting in the expanded (toggle-down) view.
• Mouse-over for advice.
Item Description
For DAC ES/GE, refer to Additional Rules for DAC ES and DAC GE on
page 9-13.
The IDU ES Ethernet function mirrors the DAC ES. Its 8x E1/DS1 function mirrors
the DAC 16x.
