9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. IV-15-69
To assist location of a circuit name, use the search options:
• Search-by-name can be optioned for ‘Starts with’ or ‘Contains’.
• For-component provides a sub-menu of installed circuit-carrying modules;
LINKs, DACs, AUX. Select one to view only its circuits in the main panel.
If a circuit has not been named, or if two or more circuits have the same name, an
error message is displayed.
When a loopback is activated its details are displayed in the Activate Circuit
Loopback panel. The loopback applies in both directions. Click De-activate to
terminate the loopback.
A circuit loopback automatically de-activates if any configuration change is
made in the Circuits screen.
Parts
The Parts screen presents:
• Part number
• Part revision
• Serial number
• Time -in-service
This data is provided for:
• All INU plug-ins except the FAN
• IDU modules
• ODUs
Refer to the example in Figure 15-27.
Time-in-service is initiated from the time the item is placed in operation. The
counter resets to zero on removal from service or power-down. The count is in
whole hours.
