3DB 23063 ADAA - Rev 004 July 2007 Vol. IV-11-1
Chapter 11. 9500 MXC Node and
Terminal Alarm Actions
The Alarm Actions screen supports mapping of alarms to/from an AUX module:
• TTL alarm inputs can be mapped to an output on the same AUX or to another
AUX within a 9500 MXC network.
• Internal alarms can be mapped to relay output on any AUX in a 9500 MXC
network.
Alarm mapping is achieved by identifying an alarm and configuring its
destination IP address, AUX and relay output port.
Refer to Alarm Actions Screen.
Alarm Actions Screen
Figure 11-1 shows a typical Alarm Actions screen. It enables:
• Alarm mapping for all AUX plug-ins installed in a Node. For a Terminal
only the single Alarm I/O position is indicated.
• Mapping of alarm inputs to local and/or remote outputs.
• Mapping of local alarms (events) to local and/or remote outputs.
Inputs and/or alarms from multiple Nodes/Terminals can be mapped to a single,
common output on any Node/Terminal in the network.
