Chapter 7. Node and Terminal Plug-ins
Vol. IV-7-86 Alcatel-Lucent
Figure 7-35. AUX Data Configuration Flow
NMS Option Overview
The data type for NMS connectivity is fixed for synchronous V.11/RS-422, 64
kbps.
For an INUe, the AUX plug-in must be inserted in slots 1 to 6 as NMS access is
only provided on these slots on its backplane. Where the NMS data function is
not selected, the AUX plug-in may also be inserted in slots 7 to 9.
AUX Plug-in Screen
Async
Select:
Select:
Sync
Port settings
Configure:
Circuits > Auxiliary Screen
Configure: Port-to-port cross-connects from AUX to
LINK (RAC) or DATA (DAC 155oM)
(1 to 3 AUX ports to 1 to 6 LINK or DATA ports)
Go to:
Go to:
Go to:
Destination Node
Configure:
As for Local Node above, ensuring correct
selection of port associations from LINK
or DATA to the destination AUX port
Local Node
Intermediate Node(s)*
Circuits > Auxiliary Screen
Configure: Port-to-port cross-connects to establish
connections between the LINK-LINK,
LINK-DATA, or DATA/DATA hops
( Ports 1 to 6, to ports 1 to 6)
*AUX plug-in
not required
Function > Data
To Next Page
