9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. II-2-13
Table 2-6. IDU ES ANSI Options
IDU ES Compatibility
IDU ES can be over-air interfaced to an INU/INUe fitted with a RAC 30v3 or
RAC 3X.
Table 2-7 indicates current compatibility for ETSI rates; Table 2-8 indicates
ANSI rates. Other rates may be supported, check with Alcatel-Lucent or your
supplier.
At the INU/INUe:
• Ethernet traffic is terminated on a DAC ES or DAC GE.
• E1/DS1 traffic is terminated on a DAC 16x or DAC 4x.
• Auxiliary data traffic and/or alarm I/O actions are terminated on an AUX.
Connect ES Ethernet
Mbps
Channel BW,
MHz
Modulation License
50 Mbps 43 10 64 QAM Base
50 Mbps
1
49 20 16 QAM Base
50 Mbps
1
49 40 QPSK Base
100 Mbps 94 20 64 QAM Upgrade 1
100 Mbps 108 20 128 QAM Upgrade 1
100 Mbps
1
1. FCC frequency efficiency restrictions mean these options are not available
for use in the 6 and 11 GHz Common Carrier bands.
2. Please check the Product Release Notes to confirm the availability of
modem profiles.
108 30 32 QAM Upgrade 1
100 Mbps
1
108 40 16 QAM Upgrade 1
150 Mbps 154 30 128 QAM Upgrade 2
150 Mbps 154 40 32 QAM Upgrade 2
150 Mbps 154 50 16 QAM Upgrade 2
200 Mbps 196 40 128 QAM Upgrade 3
200 Mbps 196 50 64 QAM Upgrade 3
