Alcatel-Lucent 9500 MXC - Remote-Mount Installation Procedure

Chapter 2. Outdoor Installations
Vol. III-2-12 Alcatel-Lucent
On the ODU, the two flange styles are:
• UDR. 6-hole or 8-hole (6/8 bolt holes depending on frequency range/
waveguide type), flush-face flange with threaded, blind holes.
• UBR. 4-hole flush-face flange with threaded, blind holes.
The corresponding mating flange styles are:
• PDR. 6-hole or 8-hole flange with gasket groove and clear holes.
• PBR. 4-hole flange with a gasket groove and clear holes.
All fastening hardware is metric.
Table 2-1. Waveguide Flange Data
Remote-Mount Installation Procedure
This topic describes the installation of a remote mount, the attachment of the
ODU to the mount, and the installation of the flexible waveguide.
Related procedures are:
• Installing the ODU Lightning Surge Suppressor; refer to Installing Lightning
Surge Suppressors on page 2-23.
• Grounding an ODU; refer to Grounding the ODU on page 2-13
• Installing the ODU cable and connectors; refer to Installing ODU Cables and
Connectors on page 2-19
Installing the Remote Mount
The remote mount attaches to a standard 112 mm (4”) pipe mount using two
saddle clamps. It can be installed either way up, and with a left or a right offset.
Firmly fasten the clamp nuts.
Freq Band Radio
Flange
Waveguide
Mating
Flange
Waveguide
Type
Spring
Washers
Reqd
Bolts
Reqd
Bolt
Type
Thread
Spec
Hole
Depth mm
Bolt Length Required
6GHz UDR70 PDR70 WR137 8 x M5 8 M5x0.8 6H 10 Flange thickness + Hole depth - 2mm
7/8GHz UDR84 PDR84 WR112 8 x M4 8 M4x0.7 6H 8 Flange thickness + Hole depth - 2mm
10/11GHz UDR100 PDR100 WR90 8 x M4 8 M4x0.7 6H 8 Flange thickness + Hole depth - 2mm
13GHz UBR120 PBR120 WR75 4 x M4 4 M4x0.7 6H 8 Flange thickness + Hole depth - 2mm
15GHz UBR140 PBR140 WR62 4 x M4 4 M4x0.7 6H 8 Flange thickness + Hole depth - 2mm
18/23/26GHz UBR220 PBR220 WR42 4 x M3 4 M3x0.5 6H 6 Flange thickness + Hole depth - 2mm
28/32/38 UBR320 PBR320 WR28 4 x M3 4 M3x0.5 6H 6 Flange thickness + Hole depth - 2mm
