3DB 23063 ADAA - Rev 004 July 2007 Vol. II-6-1
Chapter 6. 9500 MXC Performance
and Diagnostic Features
This chapter highlights some of the extensive 9500 MXC performance and
diagnostic features. Refer to:
• 9500 MXC Node on page 6-1
• 9500 MXC Terminal on page 6-6
• Operation on page 6-7
• Diagnostics on page 6-9
9500 MXC Node
9500 MXC Node provides unmatched capabilities and ease of configuration at
sites where two or more links are required, and/or where a link, or links are to be
protected for hot-standby, diversity or ring operation. Refer to:
• Platform
• Multiplexer Modes
• Capacity and Modulation
• Super PDH
• Internal Cross-connects
• Protection
• Dual Protection
• Ethernet
• Co-channel XPIC
• Auxiliary Data and Alarm I/O
