Chapter 1. Commissioning
Vol. V-1-18 Alcatel-Lucent
5. Restore the NCC and confirm no further errors. Control of the TDM clock
remains with the NPC as indicated by a green NPC Protect LED.
6. Wait at least 3 minutes after restoring the NCC (typically one minute beyond
return of CT communications), reset the BER test, then withdraw the NPC
and confirm a count of one errored second (or possibly two errored seconds).
7. Restore the NPC and confirm zero errors. The NPC Status LED becomes
green, and its Protect LED is unlit.
Commissioning Records
The As Built Report screen within CT provides access to an as-built report file
for the Node/Terminal, for saving to a folder on your PC. The file is in a csv,
Excel compatible format.
Use this report to capture configuration and other site/installation data for
appending to a final commissioning report.
Support is available from Alcatel-Lucent to assist pre and post installation
planning, as-built, and record keeping processes.
When the NCC is restored to an operational INU/INUe, its software checks the
status and verifies the configuration of each slot as recorded by the NPC. This
process takes about 3 minutes. If insufficient time is allowed, then the NCC may
force a hard reset on one or more slots, which interrupts traffic on those slots.
Always wait at least 3 minutes after power-on or restoration of an NCC before
removing its NPC.
