9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. II-1-13
9500 MXC ODUs
There are two mechanically similar ODUs, the ODU 300ep and ODU 300hp.
• ODUs are band specific and supplied with diplexers for Tx high or Tx low
working.
• ODUs are designed for direct-antenna mounting, but can be remote mounted.
Channel bandwidths range from 3.5 to 56 MHz depending on the ODU,
bandplan, and capacity/modulation option selected.
Within their band limitations the ODU 300ep and ODU 300hp are over-air
compatible.
ODU 300ep supports:
• 6 to 23 GHz
• Extended high power transceiver
• 4x to 106x E1 or 4x to 100x DS1
• 4x DS3
• 1/2x STM1/OC3
• Up to 300 Mbps Ethernet
• QPSK to 256QAM modulation
• RAC 30, RAC 40, RAC 3X, IDUs
ODU 300hp supports:
• 6 to 38 GHz
• High power transceiver
• 4x to 106x E1 or 4x to 100xDS1
•4xDS3
• 1/2x STM1/OC3
• Up to 300 Mbps Ethernet
• QPSK to 256QAM modulation
• RAC 30, RAC 40, RAC 3X, IDUs
For more information on 9500 MXC ODUs, refer to Chapter 4.
