9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. IV-7-19
Synchronized Node Protection Settings
Table 7-3. Synchronized RAC Protection Settings
Coupler Losses
Table 7-4. Nominal Coupler Losses by Frequency Band for Equal and
Unequal Couplers
Protection Type Synchronized RAC Settings
Hot Standby Frequency, Capacity, Modulation, Tx Power,
ATPC
Space Diversity Frequency, Capacity, Modulation, Tx Power,
ATPC
Frequency Diversity Capacity, Modulation
Ring Protection None
Frequency Bands,
GHz
Primary Arm Insertion
Loss, dB
Secondary Arm
Insertion Loss, dB
37.0 - 40.0 4.0 (Equal), 2.0 (Unequal) 4.0 (Equal), 7.0 (Unequal)
31.9 - 33.4
27.5 - 31.3
24.25 - 26.5
21.2 - 23.6
3.8 (Equal), 1.8 (Unequal) 3.8 (Equal), 6.8 (Unequal)
17.7 - 19.7
14.4 - 15.35
12.75 - 13.25
10.7 - 11.7
7.11 - 8.5
5.925 - 7.11
3.6 (Equal), 1.6 (Unequal) 3.6 (Equal), 6.6 (Unequal)
