Chapter 2. 9500 MXC Terminals
This chapter describes features and capabilities of 9500 MXC Terminals. Refer
to:
• PDH and SDH IDUs on page 2-1
• Ethernet IDU on page 2-10
• IDU Protection on page 2-28
• Platform Layout and Interoperation Data on page 2-34
• Configuration and Diagnostics on page 2-35
For information on 9500 MXC ODUs refer to Chapter 4.
PDH and SDH IDUs
This section introduces traffic and auxiliary interfaces and functions for:
Refer to:
• Capacity and Bandwidth Options on page 2-2
• Traffic and Auxiliary Interfaces on page 2-3
• Front Panel Layout on page 2-7
IDU Capacity
IDU 20x 5xE1 to 75xE1, or 4xDS1 to 100xDS1
IDU 155o STM1/OC3 (optical SC interface)
