Chapter 4. Licensing
Vol. IV-4-4 Alcatel-Lucent
Table 4-2. License Steps and Capacity Breaks for ANSI
IDU 20x License
From the base 20xE1/28xDS1 capacity the IDU 20x is licensed in ‘up-to’
increments:
‘Up-to’ means that an IDU 20x can be configured for any capacity less than or
equal to its maximum licensed capacity. For example, a 40xE1 license also
supports configuration of 5xE1, 10xE1, 20xE1, or 32xE1.
IDU ES 200 200 Mbps Base license + 150 Mbps upgrade.
Enables 217 Mbps.
Connect Option Nominal Capacity License
Connect ES 50 50 Mbps Base license enables 49.4 Mbps.
Connect ES 100 100 Mbps Base license + 50 Mbps upgrade.
Enables 108.1 Mbps.
Connect ES 150 150 Mbps Base license + 100 Mbps upgrade.
Enables 154.4 Mbps.
Connect ES 200 200 Mbps Base license + 150 Mbps upgrade.
Enables 196.1 Mbps.
IDU ES Option Nominal Capacity License
Type of Operation Base License License Steps
E rate 20xE1 40xE1
DS rate 28xDS1 32xDS1
